    EPISODE II
    THE 120gal STRIKES BACK

    Last fall was a dark time for the original 120gal Arts & Crafts Inspired Reef Build. Although the tank had been doing very well, a prolonged deficiency in potassium resulted in my montipora colonies health to decline and eventually crash. With the large montipora colonies now absent from the reef, a plague of blue mushrooms invaded the open reef.

    While attempts were made to control the invasion, the decision was made to shut down the reef. Plans were immediately being established for a new system for the Arts & Crafts Inspired Reef Build.

    Being obsessed with rebuilding a new and improved reef, I researched and collected countless new ideas and items for a new reef system and build thread....

    #1 jlanger, Oct 14, 2018
    Last edited by a moderator: Oct 14, 2018
